Demo
Requires a browser that will trigger touch events. Try dragging the photo on a touch screen.
FrictionTouch enables web elements to respond to touch movement as though they were being dragged on top of a surface with static friction.
When an element is dragged from an off-center position, it will progressively rotate to balance its weight along the axis of travel. So for example, if a photo is dragged horizontally from its bottom edge, it will rotate instead of staying level.
At the end of the touch gesture the direction of travel and rotation will continue given enough momentum. This enables the popular flick to dismiss gesture. On the other hand, if the touch gesture ends without much movement, the element will return to its starting position.
FrictionTouch will work in any modern browser that supports touch events and CSS animations. Browsers that do not support touch events (such as desktop browsers) will be unaffected.
Requires a browser that will trigger touch events. Try dragging the photo on a touch screen.
var element = document.querySelector('#element-id');
var options = {
flicked: (f) => console.log(`flicked: ${f}`),
complete: () => console.log('complete')
};
var frictionTouch = FrictionTouch(element, options);
frictionTouch.unbind();
Callback called when the entire gesture has finished, including all post gesture animations.
All the animations will finish either flickDuration or returnDuration milliseconds after the touchend event triggers, depending on whether the flickThreshold was reached.
Length of time in milliseconds that the animation will continue if the flickThreshold was reached. In this case the element will continue in its direction of travel and rotation.
Default: 500
Callback called when the touchend event triggers.
At this point user interaction has stopped, but the post gesture animations will continue for either flickDuration or returnDuration milliseconds, depending on whether the flickThreshold was reached.
Parameters: flicked
flicked: true if the flickThreshold was reached, and false otherwise.
Threshold for whether at the end of the touch gesture, the element will continue in its direction of travel and rotation, or return to its starting position.
A flick is achieved when, at the moment touchend triggers, the element has sufficient momentum. A threshold of x means, the ratio of the distance traveled in the x or y axis during the flickDuration period, over the width or height of the element respectively, exceeds x. Higher threshold values require more momentum to trigger a flick.
Default: 1
Scale at which the element is rotated relative to distance moved.
Higher values will result in much greater element rotation over an equal distance traveled.
Default: 2
The maximum the element will rotate relative to the balance of its weight along the axis of travel.
This limit exists to prevent unusual rotation when the element travels a longer distance.
Default: 1.5
Boolean for whether the element will return to its original position after it has been flicked.
If true and the flickThreshold has been reached, then the element transform position will be set to 0, 0 after the post gesture animations. If false and the flickThreshold has been reached, the element transform will not be reset after the post gesture animations.
The element will always return to its original position if the flickThreshold has not been reached, regardless of this value.
Default: false
Length of time in milliseconds that the animation will continue if the flickThreshold was not reached. In this case the element will return to its original position.
Default: 200
Created by Adam Chudzinski
